Starting from:
$34,074
Promotion
Specifications
- Manufacturer: Harley-Davidson
- Model: Pan America® 1250 Limited White Onyx Pearl
- Year: 2026
- Type: Adventure Touring
- Length: 2,345 mm (92.3 in.)
- Overall Width: 1,095 mm (43.1 in.)
- Overall Height: 1,510 mm (59.4 in.)
- Seat Height, Laden:
- Seat Height, Laden (Low seat position): N/A
- Seat Height, Laden (High seat position): N/A
- Seat Height, Laden (Low seat position with optional ARH suspension): 772 mm (30.4 in.)
- Seat Height, Laden (High seat position with optional ARH suspension): 797 mm (31.4 in.)
- Seat Height, Unladen:
- Seat Height, Unladen (Low seat position): N/A
- Seat Height, Unladen (High seat position): N/A
- Seat Height, Unladen (Low seat position with optional ARH suspension): 815 mm (32.1 in.)
- Seat Height, Unladen (High seat position with optional ARH suspension): 840 mm (33.1 in.)
- Static Ground Clearance: 180 mm (7.0866 in.)
- Static Ground Clearance without ARH: N/A
- Static Ground Clearance with ARH: 154 mm (6.1 in.)
- Dynamic Ground Clearance (with optional suspension): 175 mm (6.9 in.)
- Rake (steering head): 25
- Fork Angle: 25
- Trail: 108 mm (4.3 in.)
- Wheelbase: 1,580 mm (62.2 in.)
- Tires, Type: Michelin® Scorcher “Adventure”, Radial
- Tires, Front Model: Scorcher Adventure
- Tires, Front Specification: 120/70R19 60V
- Tires, Rear Model: Scorcher Adventure
- Tires, Rear Specification: 170/60R17 72V
- Fuel Capacity: 21.2 l (5.6 gal.)
- Reserve Fuel Capacity, Fuel Injection (warning light): 3.8 l (1 gal.)
- Oil Capacity (w/filter): 4.5 l (4.75 qt.)
- Transmission Capacity: N/A
- Primary Chain Case Capacity: N/A
- Coolant Capacity: 2.2 l (2.32 qt.)
- Weight, As Shipped: 284 kg (626 lb.)
- Weight, In Running Order: 300 kg (661 lb.)
- Gross Vehicle Weight Rating: 469 kg (1,034 lb.)
- Gross Axle Weight Rating, Front: 181 kg (399 lb.)
- Gross Axle Weight Rating, Rear: 302 kg (665 lb.)
- Luggage Capacity -Volume: 0.12 m3 (4.24 cu ft)
- Engine: Revolution® Max 1250
- Valves: Chain-driven, DOHC, hydraulic self-adjusting lifters, intake & exhaust VVT; four valves per cylinder
- Bore: 105 mm (4.134 in.)
- Stroke: 72.3 mm (2.846 in.)
- Displacement: 1,252 cc (76.4 cu in)
- Compression Ratio: 13.0:1
- Fuel System: Electronic Sequential Port Fuel Injection (ESPFI)
- Air Cleaner: Downdraft intake, tuned velocity stacks, washable filter media
- Exhaust: 2-into-1-into-1; catalyst in header
- Lubrication System: Semi-Dry Sump
- Drivetrain: RA1250L Pan America® 1250 Limited
- Primary Drive: Gear, 49/89 ratio
- Final Drive: Chain, 19/48 ratio
- Clutch: Mechanical, 8 plate wet, assist & slip, 1090N
- Transmission: 6-Speed
- Gear Ratios (overall) 1st: 13.11
- Gear Ratios (overall) 2nd: 9.687
- Gear Ratios (overall) 3rd: 7.509
- Gear Ratios (overall) 4th: 6.057
- Gear Ratios (overall) 5th: 5.08
- Gear Ratios (overall) 6th: 4.436
- Frame: Stressed-member, high strength low alloy steel trellis frame; stamped, cast, and forged junctions; MIG welded; aluminum forged mid-structure
- Swingarm: One-piece cast aluminum
- Front Fork: 47 mm (1.9 in) inverted fork with electronically adjustable semi-active damping control. Aluminum fork triple clamps
- Front Fork, Optional: 47 mm (1.9 in) inverted fork with electronically adjustable semi-active damping control and Adaptive Ride Height (ARH). Aluminum fork triple clamps
- Rear Shocks: Linkage-mounted monoshock with automatic electronic preload control and semi-active compression & rebound damping
- Rear Shocks, Optional: Linkage-mounted monoshock with automatic electronic preload control and semi-active compression & rebound damping and Adaptive Ride Height (ARH)
- Wheels, Optional Style Type: Annodized aluminum tubeless laced
- Wheels, Front Type: Aluminum cast, satin black
- Wheels, Front Diameter: 19 in. (483 mm)
- Wheels, Front Width: 3 in. (76 mm)
- Wheels, Rear Type: Aluminum cast, satin black
- Wheels, Rear Diameter: 17 in. (432 mm)
- Wheels, Rear Width: 4.5 in. (114 mm)
- Brakes, Caliper Type: Front: radially mounted, monoblock, 4-piston caliper; Rear: floating, single piston caliper
- Brakes, Rotor Type: Front: dual rotor, floating, tower- mounted; Rear: solid uniform expansion rotor
- Brakes, Front Diameter: 320 mm (12.6 in.)
- Brakes, Front Thickness: 4.5 mm (0.17 in.)
- Brakes, Front is dual: Yes
- Brakes, Rear Diameter: 280 mm (11 in.)
- Brakes, Rear Thickness: 5 mm (0.2 in.)
- Brakes, Anti-Lock Braking System (ABS): Standard
- Suspension Travel, Front: 191 mm (7.5 in.)
- Suspension Travel, Rear: 191 mm (7.5 in.)
- Engine Torque Testing Method: J1349
- Engine Torque: 127 Nm (94 ft-lb)
- Engine Torque (rpm): 6,750
- Power: 150 HP / 112 kW @ 8750 rpm
- Lean Angle Testing Method: J1168
- Lean Angle, Right (deg.): 42
- Lean Angle, Left (deg.): 42
- Fuel Economy Testing Method: Estimated City/Hwy
- Fuel Economy: 5.1 l/100 km (46 mpg)
- CO2 Emissions Testing Method: N/A
- CO2 Emissions: N/A
- Stationary Noise (BRZ only): N/A
- Battery: Sealed, maintenance-free, absorbed glass mat (AGM) battery, 12V, 17.5Ah, 310 CCA at 0°F
- Charging: Three-phase, 45 Amp system (390 Watts @13 Volts, 1300 rpm, 585 Watts max power @ 13 Volts, 2500 rpm)
- Starting: 0.9 kW electric with direct drive starter motor engagement
- Lights (as per country regulation), Headlamp: Daymaker® Adaptive LED Headlamp with 6-segment LED banking lamp
- Lights (as per country regulation), Tail/Stop: All LED Tail/Stop lamp with signature tail lighting
- Lights (as per country regulation), Front Signal Lights: LED Bullet Turn Signals
- Lights, Rear Turn Signals: LED Bullet Turn Signals
- Gauges: 6.8 inch (173 mm) viewable area TFT display with speedometer, gear, odometer, fuel level, clock, trip, ambient temp, low temp alert, side stand down alert, TIP over alert, cruise, range and tachometer indication BT capable - phone pairing to access phone calls, music, navigation (H-D App ONLY)
- Auxiliary Lamps: Fog lamps & driving beams
- Electric Power Outlet: USB C-Type , Output 5V at 2.4 Amp
- GPS System: N/A
- Reverse: N/A
- Infotainment system: N/A
- Screen Size: 6.8 in (173 mm)
- Type: Color TFT w/ Touch
- Watts Per Channel: N/A
- Speakers: N/A
- Speaker Size: N/A
- Headset Specifications (if equipped): Bluetooth
- AM: N/A
- FM: N/A
- MW: N/A
- LW: N/A
- Weather Band (WB): N/A
- SD Card, Flash Drive and MP3 - via USB Connection: N/A
- Languages: Arabic, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (default), Finnish, French (Canada/France), German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal/Brazil), Indonesian, Russian, Slovak, Spanish (Mexico/Spain), Swedish, Thai, Turkish, Vietnamese
- Hands-free Mobile Phone - via Bluetooth: Standard
- Voice Recognition Languages: Phone functions only: Phone dependent
- Voice Recognition Languages: Tuner/Media/Navigation: Phone dependent
- Rider/Passenger Intercom: Headset function only
- Vehicle Information Screen (Air temperature, oil pressure and EITMS): TPMS, Engine temp, Battery Voltage, Ambient Air Temp
- Text-to-Speech (TTS) Languages: Phone dependent
- USB: Charging and Instrument update, USB-C, 5V, 3A
- Phone Connectivity:
- Bluetooth: Phone/Media Supported
- Navigation - via Bluetooth: H-D Mobile App
